Stealth™ Intake Manifold 351 Windsor IMCA Legal
This 351 Windsor intake manifold is part of the Weiand Nostalgia Series of intake manifolds. Weiand Nostalgia Series intake manifolds are made using the original tooling and may have minor appearance imperfections that do not affect the functionality of the part. These minor blemishes are a natural part of the casting process when using the original sand casting tooling.
- Port Size: 1.82” height 1.05" width
- Power band: 1500-6800 RPM
- High Rise Dual Plane Design
- No EGR provisions
- Square Carburetor Mounting Flange
- Weiand Nostalgia Series Intake Manifold
- Height: Front 4.37", Rear 5.06"
Information:
Fits GT-40 and TFS heads.
Application Summary:
| Year |
Make/Model |
| 1984-1987 |
Ford Bronco |
| 1984-1987 |
Ford E-150 Econoline |
| 1984-1987 |
Ford E-150 Econoline Club Wagon |
| 1984-1987 |
Ford E-250 Econoline |
| 1985-1987 |
Ford E-250 Econoline Club Wagon |
| 1985-1987 |
Ford E-350 Econoline |
| 1985-1987 |
Ford E-350 Econoline Club Wagon |
| 1984-1987 |
Ford F-150 |
| 1984-1987 |
Ford F-250 |
| 1984-1987 |
Ford F-350 |
| 1969 |
Ford Fairlane |
| 1973-1974 |
Ford Gran Torino |
| 1969-1970 |
Ford Mustang |
| 1969 |
Ford Ranchero |
| 1972-1974 |
Ford Ranchero |
| 1969 |
Ford Torino |
| 1972-1974 |
Ford Torino |
| 1977 |
Lincoln Versailles |
| 1969 |
Mercury Comet |
| 1969-1970 |
Mercury Cougar |
| 1974 |
Mercury Cougar |
| 1969 |
Mercury Cyclone |
| 1969 |
Mercury Montego |
| 1972-1974 |
Mercury Montego |
| Attributes |
| ASIN |
B000CQDJ8W |
| Barrel |
Four |
| Barrels |
4, 4 |
| Basic Operating RPM Range |
1500-6800 |
| Brand |
Weiand, Weiand |
| CNC Ported |
No |
| California Proposition 65 |
No |
| Carburetor Flange |
4150 Square Bore |
| Category |
Air and Fuel Delivery, Air and Fuel Delivery |
| Color |
Natural, Natural |
| Construction |
Cast, Cast |
| Country of Origin (Primary) |
US |
| Cylinder Head Port Shape |
Rectangle |
| Cylinder Head Type |
Standard |
| Deck Height |
9.5 |
| EGR Port |
No |
| Emission |
Without EGR |
| Emission Code |
3, 3, Off Road |
| Engine |
Ford Small Block V8, Ford 351W |
| Engine Make/Size |
Ford Small Block V8 |
| Finish |
Satin, Satin |
| Flange Style |
4150 Square Bore |
| Front Height |
4.370 in., 4.37 inch |
| Front Maximum Height |
4.37, 4.37 |
| Fuel Injectors Included |
No |
| Fuel System Type |
Carb, Carb |
| GTIN |
00032474802309 |
| Gasket Or Seal Included |
No |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8409915085 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Manifold Type |
High Rise, High Rise |
| Material |
Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Plenum Finish |
Satin, Cast |
| Position |
Lower |
| Product Type |
Intake Manifold, Intake Manifold |
| RPM Power Band |
1500-6800, 1500-6800 |
| RPM Range |
1500-6800 |
| Rear Height |
5.060 in., 5.06 inch |
| Rear Maximum Height |
5.06, 5.06 |
| SDR Required Flag |
N |
| Sale Category |
Air and Fuel Delivery |
| Single Or Dual Plane Type |
Dual |
| Throttle Body Gasket Included |
No |
| Usage |
Street/Strip |
| Vacuum Ports |
Yes |
| Warning |
California Proposition 65 |
| Warranty |
Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
